3-phase spot EURO CUBE 2 M PHASE flat, square, cardanic IP20, black, white dimmable

High-Quality 3-Phase LED Spotlight with Excellent Color Rendering

The LED 3-phase spotlight EURO CUBE 2 M PHASE from SLV impresses with its outstanding color rendering, featuring a CRI value of over 90 Ra and a color rendering grade of 1A. This ensures a natural and vivid representation of colors, especially skin tones. With its neutral white light color of 4000K, the spotlight is ideal for creating clear and pleasant lighting conditions that prevent color distortions.

Efficient and Durable Lighting Solution

The luminaire has a power consumption of 14 watts and a luminous flux of 1700 lumens, corresponding to a luminous efficacy of 121.43 lm/W. This guarantees energy-efficient lighting while providing high brightness. With an average lifespan of 50,000 hours, the spotlight is particularly durable and reduces long-term maintenance and replacement costs.

Flexible and Comfortable Design for Optimal Light Direction

The spotlight is cardanically mounted, allowing it to be easily rotated and swiveled to position the 40° wide light beam exactly where it is needed. The compact design with dimensions of 9.5 x 12.5 x 15.8 cm allows for unobtrusive integration into various lighting systems. The modern, square design is available in black and white, with the housing made of robust aluminum.

Innovative Technology for Safety and Sustainability

Equipped with an integrated passive heat sink, the spotlight ensures effective heat dissipation, which further extends the lifespan of the LEDs. The dimming function operates via phase-cut control and enables stepless adjustment of light intensity. The current-controlled LED driver is replaceable, enhancing the product’s sustainability and allowing easy maintenance by qualified personnel. Protection class 2 and IP20 rating ensure safe operation.

Practical Accessories and Versatile Applications

Included in the delivery are a 3-phase adapter and a suitable driver. Installation is carried out on a 3-phase track, which is available separately. Additionally, optional filters such as honeycomb filters are available to further optimize the light. The maximum number of spotlights that can be connected to a circuit breaker is up to 61 units with a C16 breaker and 38 units with a B16 breaker, allowing flexible planning of larger lighting installations.
